Automatic toll barrier gate with optional foam padding to minimize liability
WEJOIN Barrier Gate Profile
This barrier gate offers a reliable and efficient method to ensure only authorized users are allowed access to each area of space.
The DZ102 is an attractive barrier gate that is easily capable of handling high volume and abusive conditions.
The compact unit makes it simple to construct a multiple-lane set-up while the various colors allow you to match this parking barrier perfectly to your parking lot.
Automatic Boom Barrier Gate More Features
1.- The traffic barrier is widely used for the facilities of parking, traffic, or toll system.
2.- Arms can be chosen from 3 meters to 6 meters.
3.- This type of barrier could match with a direct boom( pole), fold boom, Or fence boom.
4.- Advanced manual release. The clutch key can be used to open the clutch when electricity is cut off.
5.- All the process is soft without any noise and shaking.
6.- This barrier gate has many input terminals for photocell, Airwave switch, loop detector, back-up battery(for DC Motor), toll
gate system, and output terminals for the lamp.
7.- Housing color: yellow,red ,blue,orange,white (optional)
8.- Boom arm direction can be chosen from leftward to rightward.
9.- Auto warming up, suitable for a cold environment.
10- Controlling way: wireless or wiring multiple push-button for OPEN, CLOSE, STOP function.
Parking Barrier Gate Motor speed and boom type
| Boom type | Boom length (M) | Opening time(S) | Height between boom and ground(M) |
| Fence boom, two-level | 4.5M≥L | 6S | H=0.9M |
Maintenance
1. Keep the barrier gate clean
2. Check the joints every month in case of any loose parts.
3. Check the spring elasticity after the barrier gate runs 30000 times
4. Check the easily worn-out parts (like spring, limit switch) every half year and renew it.
5. Remote control distance will be shortened or not work in cases like big object screening, battery exhausting, extreme weather.
